EPR-CSP-NYLONE BRAIDING-CSP HD HOFR

Technical Details

Design Standard : As per IS 8130, IS 9968, IS 6380

Conductor : Annealed Bare Copper / Nickel Plated Copper /

Tinned Plated Copper / Silver Plated Copper

Conductor Size : Variant as per customer specifications

Conductor Type : Solid wire / Flexible

No of Core : Single Core / Multi Core

Core Insulation : EPR Insulation

Core Formation : Twisted / Flat

Inner Sheath Insulation : CSP Insulation

Braiding : Nylone Yarn Braiding

Outer Sheath Insulation : CSP HD HOFR Insulation

Core Colour : As per Customer specification.

Outer Sheath Colour : As per Customer specification..

Cable Temp. Range : Up to 90 Deg C

Voltage Grade : Upto 1100 V
